Ray Diagram Of A Convex Mirror
Ray Diagram Of A Convex Mirror

You know that little sticker on your car’s side mirror? The one that says Objects in mirror are closer than they appear*?

It’s not a suggestion. It’s a warning baked directly into the physics of a convex mirror. And if you’ve ever tried to draw the ray diagram of a convex mirror in a physics lab, you know exactly why that warning exists. The diagram explains the distortion. It shows you why your brain — calibrated for flat mirrors — gets tricked every single time.

Let’s break down how to draw it, why it works, and where almost everyone goes wrong.

What Is a Convex Mirror

A convex mirror is a curved reflective surface where the reflecting side bulges outward, away from the center of curvature. On the flip side, think of the back of a shiny spoon. Or the big bubble mirrors you see at blind corners in parking garages.

Because the surface curves out, it spreads light rays apart. That’s why the technical name is a diverging mirror. They reflect outward. Parallel rays hitting the surface don’t converge at a real point in front of the mirror. To your eye — or a camera sensor — they look* like they’re coming from a single point behind* the mirror.

That point is the virtual focus.

The center of curvature (C) sits behind the mirror too, twice as far from the pole (P) as the focal point (F). Think about it: the principal axis runs horizontally through P, C, and F. Everything in a ray diagram of a convex mirror happens relative to that line.

Why It Matters

You see these mirrors every day. Now, side-view mirrors on vehicles. That said, security domes in convenience stores. The reflective orbs at hospital hallway intersections. They all do one job: expand the field of view.

A flat mirror shows you a 1:1 slice of reality. A convex mirror compresses a wider angle into that same visual space. You see more — but smaller. That said, that trade-off is deliberate. On a highway, seeing that* a car is in your blind spot matters more than judging its exact distance.

In physics class, the ray diagram of a convex mirror is the standard way to prove why the image is always virtual, always upright, and always diminished. No special object positions that flip the image upside down like a concave mirror. No exceptions. It is the most predictable mirror in optics — which makes it a favorite for exam questions.

How to Draw the Ray Diagram

This is the part where most students lose marks. Not because the physics is hard. Because the drawing discipline is sloppy.

Grab a sharp pencil. A ruler. A compass if you have one. Draw the principal axis as a horizontal line. Practically speaking, mark the pole (P) near the left. Because of that, mark F and C to the right* of P (behind the mirror). Draw the mirror as a shallow curve bulging left, centered on C.

Place your object — an upright arrow — on the left side of the mirror, anywhere on the principal axis. Height doesn’t matter much, but keep it reasonable.

Now the three principal rays. You only need two to locate the image, but drawing all three checks your work.

Ray 1: Parallel to Principal Axis

Draw a ray from the top of the object arrow, traveling left-to-right, parallel to the principal axis. It hits the mirror. Now — this is the critical step — reflect it as if* it came from the focal point F behind the mirror.

Use your ruler. Line up the point where the ray hits the mirror with F. So draw a dashed line extending backward (to the right) from the mirror surface through F. Consider this: the solid reflected ray goes leftward, diverging. The dashed line shows the apparent* origin.

Ray 2: Toward the Center of Curvature

Draw a ray from the object tip heading toward C (behind the mirror). Since C is the center of the sphere, this ray hits the mirror normal* to the surface — perpendicular. It reflects back along the exact same path.

For more on this topic, read our article on how to find the area of the base or check out why is fluorine the most electronegative element.

Again, draw the reflected part as a solid line going left. The incident part (approaching the mirror) is often drawn dashed since it’s a virtual path behind the mirror. It doesn’t matter much, but be consistent.

Ray 3: Toward the Focal Point

Draw a ray from the object tip heading toward F (behind the mirror). This one hits the mirror and reflects parallel* to the principal axis.

Why? Reversibility of light. If a parallel ray reflects as if* from F, then a ray aimed at F must reflect parallel. Same geometry, reversed.

Locating the Image

Extend the reflected rays (solid lines going left) backward behind the mirror using dashed lines. Where they appear to intersect — that’s the top of your image arrow.

Draw the image arrow from the principal axis up to that intersection. It will be:

  • Behind the mirror (virtual)
  • Upright (same orientation as object)
  • Smaller (diminished)
  • Closer to the mirror than the object

Move the object closer to the mirror. The image gets larger — but never larger than the object. Think about it: move it to infinity. Also, the image shrinks to a point at F. The ray diagram of a convex mirror always* tells this same story.

Common Mistakes

I’ve graded hundreds of these. The same errors show up every time.

Drawing real rays behind the mirror. The reflected rays diverge in front of the mirror. Only the extensions* (dashed lines) go behind. If you draw solid lines continuing behind the glass, you’re implying light travels through the mirror. It doesn’t.

Confusing F and C positions. In a convex mirror, both are behind* the mirror. Positive focal length in the sign convention? No. Focal length is negative* for convex mirrors. The diagram shows F and C on the right. The sign convention puts them at negative distances. Don’t mix the visual diagram with the sign convention without thinking.

Making the image touch the mirror. The image forms between* P and F. Always. If your image arrow sits right on the mirror surface, your rays are wrong. Check your extensions.

Skipping the dashed lines. Examiners look for them. They prove you

understand the difference between real and virtual paths. Without dashed lines showing where the rays appear* to come from, your diagram is incomplete.

Forgetting that the image is always virtual. Some students draw the image in front of the mirror, treating it like a concave mirror case. Remember: convex mirrors always produce virtual, upright, and diminished images regardless of object position.

The Big Picture

Convex mirrors aren't just physics problems — they're everywhere. In practice, passenger side mirrors, security mirrors in stores, road mirrors at blind corners. They sacrifice detail for coverage, giving you a wider field of view at the cost of making objects appear smaller and farther away.

It looks simple on paper, but it's easy to get wrong.

That's why passenger side mirrors carry the warning: "Objects in mirror are closer than they appear." The physics isn't lying — the mirror just shows you a compressed view of what's really there.

Once you understand how convex mirrors manipulate light through their characteristic outward curve, you're not just solving ray diagrams. You're understanding how we've engineered safety and visibility into our everyday world.
